Conduit Hangers
Product Features
- Manufactured in 316 stainless steel for superior corrosion resistance, exceptional strength, and outstanding performance in harsh environments.
- Produced with high polished finish and mechanical strength designed to withstand vibration, impact, and harsh conditions without compromising integrity.
- Permanent fiber laser identification eliminates contamination risks and maintains traceability without surface marring.
- Heavy‑gauge stainless steel construction maintains shape and support under mechanical stress.
- Type 316 stainless steel nut and bolt included.
Certifications
- UL/cUL 2239 Listed
- UL File # E516500
- RoHS compliant
- REACH compliant
Applications
- RMC’s type 316 stainless steel Conduit (Mini) Hangers are built for heavy‑duty performance, providing secure support and mounting of stainless steel Rigid Conduit to multiple structural members in corrosive or demanding environments.
Specifications
| Part Number | Trade Size | Height | Length | C | D | E | T | WT/PC (lbs.) |
|---|---|---|---|---|---|---|---|---|
| SR6MH05 | 1/2” | 0.750” | 1.930” | 0.840” | 0.840” | 0.880” | 0.050” | 0.07 |
| SR6MH07 | 3/4” | 0.870” | 2.360” | 0.870” | 1.050” | 0.950” | 0.050” | 0.08 |
| SR6MH10 | 1” | 0.870” | 2.620” | 1.020” | 1.310” | 1.220” | 0.050” | 0.10 |
| SR6MH12 | 1-1/4” | 0.870” | 3.270” | 1.200” | 1.670” | 1.550” | 0.050” | 0.12 |
| SR6MH15 | 1-1/2” | 1.260” | 3.440” | 1.080” | 1.900” | 1.660” | 0.060” | 0.18 |
| SR6MH20 | 2” | 1.260” | 4.150” | 1.100” | 2.370” | 2.050” | 0.060” | 0.22 |
| SR6MH25 | 2-1/2” | 1.180” | 4.730” | 1.100” | 2.870” | 2.390” | 0.060” | 0.28 |
| SR6MH30 | 3” | 1.180” | 5.430” | 1.140” | 3.500” | 2.690” | 0.060” | 0.32 |
| SR6MH40 | 4” | 1.260” | 6.230” | 1.100” | 4.500” | 3.250” | 0.060” | 0.37 |
