Split Ring Clamps
Product Features
- Manufactured in 316 stainless steel for superior corrosion resistance, exceptional strength, and outstanding performance in harsh environments.
- Produced with high polished finish and mechanical strength designed to withstand vibration, impact, and harsh conditions without compromising integrity.
- Permanent fiber laser identification eliminates contamination risks and maintains traceability without surface marring.
- Heavy-gauge stainless steel construction maintains shape and support under mechanical stress.
- Suitable for both vertical and horizontal conduit runs, offering installation flexibility across a wide range of applications.
- Type 316 #10-24 UNC stainless screws included.
- Body: Type 316 Stainless Steel
- Screws: Type 316 Stainless Steel
Certifications
- UL/cUL 2239 Listed
- UL File # E516500
- CSA C22.2 NO. 18.4-15
- ASTM A743
- RoHS compliant
- REACH compliant
Applications
- RMC’s type 316 stainless steel Split Ring Clamps are built for heavy-duty performance, providing secure support and mounting of stainless steel Conduit to multiple structural members in corrosive or demanding environments.
- RMC’s Split Ring Clamps are engineered to maintain a precise standoff between raceway and mounting surfaces. This clearance is critical in wash-down environments where water and cleaning chemicals are regularly applied, preventing moisture and contaminants from becoming trapped between the conduit system and the mounting surface.
Specifications
| Part Number | Trade Size | A | B | C | D | E | F | G | H | WT/PC (lbs.) | THREADS |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SR6SRC05 | 1/2" | 2.156” | 0.518” | 0.276” | 0.839” | 0.128” | 0.075” | 1.614” | 1.102” | 0.10 | 3/8”-16 UNC |
| SR6SRC07 | 3/4" | 2.504” | 0.531” | 0.323” | 1.071” | 0.118” | 0.059” | 1.969” | 1.433” | 0.11 | 3/8”-16 UNC |
| SR6SRC10 | 1" | 2.661” | 0.531” | 0.382” | 1.339” | 0.138” | 0.098” | 2.126” | 1.732” | 0.13 | 3/8”-16 UNC |
| SR6SRC12 | 1-1/4" | 3.217” | 0.551” | 0.374” | 1.685” | 0.150” | 0.098” | 2.677” | 2.055” | 0.15 | 3/8”-16 UNC |
| SR6SRC15 | 1-1/2" | 3.453” | 0.610” | 0.374” | 1.913” | 0.150” | 0.098” | 2.846” | 2.307” | 0.18 | 3/8”-16 UNC |
| SR6SRC20 | 2" | 3.917” | 0.610” | 0.374” | 2.402” | 0.150” | 0.098” | 3.287” | 2.835” | 0.21 | 3/8”-16 UNC |
