Four Hole Tee Plate
Product Features
- Manufactured in 316 stainless steel for superior corrosion resistance, exceptional strength, and outstanding performance in harsh environments.
- Hygienic polished surface improves cleanability, resists microbial buildup, and delivers a consistent, professional appearance.
- Designed to fit standard 1-5/8” stainless steel strut channels.
- Heavy-duty design provides a stable base for strut/channel framing, ensuring long‑term reliability of conduit and equipment supports.
Certifications
- ASTM A240
- RoHS compliant
- REACH compliant
Applications
- RMC’s type 316 stainless steel 4‑Hole Tee Plate is designed to provide a secure, corrosion‑resistant connection point for strut/channel framing systems. With four precision‑drilled holes, this plate allows for versatile mounting of strut to support conduit, piping, or equipment supports to beams, walls, or other structural members.
Specifications
| Part Number | A | B | C | D | WT/PC (lbs.) |
|---|---|---|---|---|---|
| SR6TP4H | 5.375" | 0.250" | 3.375" | 1.625" | 0.72 |
